BW DOCK2-0-1G-00-G GasAlertClip Extreme Carbon Monoxide (CO) Docking Module for MicroDock II Automatic Test & Calibration Station-

Downloads: datasheet manual

BW DOCK2-0-1G-00-G GasAlertClip Extreme Carbon Monoxide (CO) Docking Module for MicroDock II Automatic Test & Calibration Station

Model: DOCK2-0-1G-00-G

Plug the Carbon Monoxide module into the MicroDock II Automatic Test & Calibration Station and start managing it.

Sale Price $395.00 USD
Regular Price $500.00 USD
Availability 1 to 2 Weeks

BW MicroDock II Automatic Test & Calibration Station Series Offers

The MicroDock II is an automated docking station for portable single gas and multi gas detectors from BW Technologies. The base station is the master unit responsible for recognizing, calibrating, testing, charging and event recording for each gas detector that is docked into a docking module. Each base station can manage up to 10 different detectors in their own attached docked module, six of which can have charging built in.


  • Fully automatic "hands-free " calibration & functional bump test
  • Automatically verifies performance of audible and visual alarms
  • Stores and updates calibration records in the MicroDock II, as well as in the GasAlertMicro 5, GasAlertMicro 5 PID, GasAlertMicro, GasAlertMicroClip and GasAlert Extreme detectors
  • No computer required
  • Entirely self-contained
  • Fully portable
  • Lightweight and mobile
  • Operates via line power or a set of four C-cell batteries
  • Add additional self-contained docking modules to system via simple, plug-in connections-no external pressure transducers or gas lines necessary
  • Simplify record keeping
  • Verify proper performance
  • Reduce maintenance costs
  • Multiple MicroDock II systems can be connected via a LAN
  • Multi-language support in English, French, German, Spanish, and Portuguese

Supported Models

  • GasAlertMicroClip
  • GasAlert Quattro
  • GasAlertMax XT
  • GasAlertMicro 5 (including PID and IR models)
  • GasAlertClip Extreme (including 24 months and 36 months models)
  • GasAlert Extreme
Compatibility Functions
Function GasAlertClip GasAlert Extreme GasAlertMicroClip XT GasAlertQuattro GasAlertMax XT II GasAlertMicro 5 Series
Bump Check
Download Events
Download Data

BW MicroDock II Automatic Test & Calibration Station Series Specifications

General Specifications
Size 8.3 x 10.4 x 3.2 in. / 21.2 x 26.3 x 8.2 cm
(base station plus one docking module
Power Supply 6V wall adaptor or four C-cell batteries
External interface USB 2.0 interface for PC (USB 2.0 full speed)
Pump DC motor, micro-diaphragm; 6V PCB mount
Flow rate 300 ml/min. (typically
Solenoid Built-in (docking modules)
Command Keys Base station
Menu navigation Docking module
One touch bump-test initiation One touch calibration initiation One touch data transfer (specific products)
LED indicators Yellow "TEST", Green "PASS", Red "FAIL"
Certifications and approvals Ordinary Location approved IEC 61010 / C22.2 No. 61010
European Conformity
Click here for complete specifications on the BW DOCK2-0-1G-00-G

How to Select the Right Gas Detection Solution

by Don Galman

There are many gas detection products on the market that might appear to be the same, but a closer inspection of specification, functionality and features reveals major differences in what products can do and the potential value they can offer. Similarly, individual applications are also unique in their respective designs, needs and processes undertaken.

Know your site risks

Before beginning to consider gas detection equipment, a risk assessment needs to be conducted. Any company employing staff has the obligation to conduct risk assessments to identify potential hazards and these can include potential gas, vapor or Oxygen deficiency risks. If gas hazards are identified, gas detection is applicable as a risk reduction method.

Identifying the prime objective

Depending on the processes being undertaken and the gases being detected, remote or off-site alarm notification plus event data logging/reporting may also be required for Health and Safety management records. Another factor impacting on the need for enhanced reporting functions might be regulatory compliance or a condition of insurance.

Ask the right questions

Having identified the primary objective, the suitable equipment is selected by asking a number of key questions. These fall into three broad categories:

  • The gases to be detected and where they may come from
  • The location and environmental conditions where detection is to take place
  • The ease of use for operators and routine servicing personnel
Identify the gases to be detected and where they may come from

The gases to be detected should be identified by the risk assessment, however experienced gas detection equipment manufacturers and their approved distributors are often able to help in this process, based on their experience of similar applications. However, it is important to remember that it is the end-user’s responsibility to identify all potential hazards. It is also essential to identify the potential source of a gas release as this helps determine the number and location of detectors required for a fixed gas detection system.

Consider the environmental conditions

The performance, accuracy and reliability of any gas detection equipment will be affected by the environmental conditions it is subjected to. Temperature, humidity and pressure levels at the location all have a direct bearing on the type of equipment that should be selected. Additional factors such as potential variations resulting from a production process itself, diurnal/nocturnal fluctuations and seasonal changes may also affect the type of device which is suitable.

Understand product functionality

The next area of consideration relates to additional product functionality. Aspects like wiring configuration are important, especially when retro-fitting into an existing application. If the apparatus is being integrated into a separate safety system, certain communication protocols may also be required such as HART®, Lonworks or Modbus®. Consideration will also need to be given regarding the requirement for local displays on transmitter units and local configuration of the unit and gas displays may also be a useful addition.

Measure the ease of use for operators and routine servicing personnel

Routine maintenance is another important consideration. Some gases and vapors can be detected with a number of different sensing technologies, e.g. Hydrocarbon gases with catalytic beads or Non-dispersive Infrared NDIR. Catalytic beads do not provide fail-to-safety operation and therefore can require a high frequency of routine maintenance, however NDIR based solutions tend to have a higher initial purchase price, but may require less routine maintenance. In-house resource to undertake such routine maintenance needs to be identified and in the absence of such a resource, budgeting for third party maintenance is an important factor in selecting the right equipment.

Need Help Selecting the Right Solution?

If you have questions about any of our gas detection products or services, please don’t hesitate to contact us. Whether you need a hand finding a new product or need help with your current system, just ask our team of Factory Trained Experts.

comments powered by Disqus

What's included with the BW MicroDock II Automatic Test & Calibration Station Series

  • BW MicroDock2 Automatic Test & Calibration Station
  • 128 MB Delkin MultiMediaCard (MMC) inserted
  • Two to four calibration gas hoses (depending upon order at the time of purchase) with quick connect fittings
  • Inlet filter assembly
  • USB cable
  • CD: MicroDock II User Manual and MicroDock II Quick Reference Guide translations
  • Power adapter
  • Charger adapter (charger models only)
  • Fleet Manager II CD ROM
  • MicroDock II Quick Reference Guide
  • Batteries (four replaceable C-cell alkaline batteries)
